Schneider Electric XS8C2A1MAU20

Schneider Electric XS8C2A1MAU20 by Square D by Schneider Electric

Call for Price
  • Part Number: XS8C2A1MAU20
  • UPC: 00785901975434
  • Availability:
Quantity:
Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Product Overview
SQD XS8C2A1MAU20 ACDC NO 2WIRE FLUS
Specifications
Details
Category Level 1:
Industrial Control
Category Level 2:
Proximity Sensors
Category Level 3:
Inductive, Block-Rectangular Style
Accuracy:
<=3%
Category Name:
Inductive, Block-Rectangular Style
Connection Type:
3-Pin 1/2-20 UNF Male
Contact Configuration:
1NO
Country:
USA
Enclosure Type:
IP65/IP67/IP69K
Environmental Conditions:
-40 to 185 deg F Storage Temperature, 25 gn Vibration Resistance, 50 gn Shock Resistance
Frequency Response:
<=25/<=50 Hz
Length:
2.0
Material:
PBT
Measuring Range:
0 to 0.63 in
Mounting Type:
Flush
Output Type:
Discrete
Response Time:
<=1.2 ms
Sensing Distance:
0.79 in
Sensing Method:
Inductive
Sensing Position:
5-Position Turret Head
Series:
XS8
Size:
40 mm L x 70 mm W x 40 mm H
Standard/Approvals:
California Provision: WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause
Temperature Rating:
-25 to 70 Deg C
Type:
Fixed Flat Form
Unspsc:
39122230
Voltage Rating:
20 to 264 VAC/VDC, 24 to 240 VDC, 24 to 240 VAC
Volume:
10.0
Weight:
0.0
Additional Information
Manufactured By:
Square D by Schneider Electric
